3 Point Tractor Disc Harrow
Tractor disc harrows are used for ground breaking-up, soil lump smashing preparing soil before seeding, loosening the soil and crop residues mixing into soil as green manures.
Description
3 point tractor disc harrow
3 Point Tractor Disc Harrow Introduction
3 point tractor disc harrow can easily be hitched onto the tractor. It provides effective work on the field. Yibiyuan offers such machines of fuel efficient performance at affordable prices.
3 Point Tractor Disc Harrow Features
1) Harrow blades are made of #65 manganese spring steel, after heat treatment, the hardness is 38-46HRC, features high tensile strength.
2) The square shaft is made of # 45 steel, which has been quenched and tempered for hardness and toughness, and is not easy to break or bend.
3) The bearing seat adopts an all-inclusive bearing seat, which is well sealed and can be conveniently maintained by adding lubricants.
3 Point Tractor Disc Harrow Parameter (specification)
Model | 1BQX-1.1 | 1BQX-1.3 | 1BQX-1.5 | 1BQX-1.7 | 1BQX-1.9 | 1BQX-2.2 | 1BQX-3.4 |
Working Width (mm) | 1100 | 1300 | 1500 | 1700 | 1900 | 2200 | 3400 |
Depth(cm) | 10 | 10 | 10 | 10 | 14 | 14 | 14 |
Harrow Count (piece) | 12 | 14 | 16 | 18 | 20 | 24 | 42 |
Net Weight (KG) | 200 | 220 | 240 | 260 | 290 | 350 | 1108 |
Power (HP) | 12-15 | 15-18 | 25-30 | 30-35 | 35-40 | 55-60 | 80-100 |
Disc Diameter (mm) | 460 | 460 | 460 | 460 | 460 | 460 | 460 |
Connection Type | 3 point hitch | ||||||
3 Point Tractor Disc Harrow Display
FAQ
Q: Who are you?
A: We are based in China. Our company have exported agricultural machinery worldwide for over 10 years.
Q: How can you guarantee the product quality?
A: Always test incoming materials before production; Inline spot check during manufacturing;
100% final Inspection before shipment.
Q: What can we buy from you?
A: Farming tractors, cultivators and various other agricultural implements.
Q: Why should we buy from you instead of other suppliers?
A: We offer you reliable quality, reasonable price and superior prices.
Q: What payment terms do you accept?
A: You can pay by T/T, L/C at sight, Western Union, etc.
